8 Cavity 700ml High Speed PET Top Linear Automatic Plastic Bottle Manufacturing Machine
Technical Parameters
Product Details:
The PET blow molding machine JS-8C-1.5L is a state-of-the-art piece of equipment designed for high-volume production of PET bottles. With its advanced technology and precision engineering, this machine is ideal for manufacturers looking to enhance their bottling capabilities. The JS-8C-1.5L model boasts a series of impressive features that cater to the needs of the beverage and packaging industries.
With a total of 8 cavities, the JS-8C-1.5L PET blow molding machine can produce up to 15,000 bottles per hour, ensuring a high output for your production line. It is capable of manufacturing bottles with a maximum capacity of 1.5 liters, making it versatile for a range of product sizes. The machine can handle bottles with a maximum outer diameter of the finish up to 30mm and a maximum outer diameter of the bottle up to 95mm, as well as a maximum height of 350mm.
The heating system of the JS-8C-1.5L is robust, with a heating power of 80 KW and a heating spacing of 38mm, ensuring even and efficient heating of the preforms. The bottle spacing of 105mm allows for precise placement and molding. The machine is powered by a total of 106 KW, with a servo motor power of 21 KW and other motor power of 5 KW, indicating its high performance capabilities.
For air consumption, the JS-8C-1.5L operates at a low pressure of 7 Bar with a consumption of 1000 L/min and a blowing pressure of 35 Bar with a high pressure air consumption of 8000 L/min. The temperature range for operation is between 10-12C, with a flow rate of 50 L/min and a rated power of 5 HP for the operating pressure range of 3-5B.
The dimensions of the machine are 6.21.52.6 meters, and it weighs approximately 7000 KG, reflecting its robust and sturdy construction. The PET blow molding machine JS-8C-1.5L is built to provide reliable and efficient service, making it an essential component of any modern bottling facility.
| Project | UNIT | JS-8C-06L |
| Production capacity | BPH | 15000-16000 |
| Number of Cavity | 8 | |
| Clamping force | KN | 470 |
| Mould opening stroke | mm | 100 |
| Stretch stroke | mm | 280 |
| Max. Container Volume | L | 0.7 |
| Max. Neck Size | mm | 30 |
| Max. Bottle diameter | mm | 70 |
| Max. Bottle height | mm | 280 |
| Installed Power | Kw | 82 |
| Max. Heating Power | Kw | 66 |
| Operating Air Pressure | Kg/cm2 | 8 |
| Operating Air Consumption | liters/min | 1000 |
| Blowing Air Pressure | KG/cm2 | 35 |
| Blowing Air Consumption | liters/min | 6500 |
| Cooling water Pressure | Kg/cm2 | 4-5 |
| Cooling water Temperature | °C | 10-20 |
| Cooling water Flow | liters/min | 100 |
| Measurement (L x W x H) | M | 5.1*1.9*2.3 |
| Machine Weight | Tons | 6.5 |
Product Advantages
Build over two decades of experience in PET blow molding, Johsean's blow molding solutions are dedicated to delivering excellence in quality, safety, adaptability, competitiveness, and ecological advantages. Our team of experts specializes in tailoring solutions to match your product and production requirements at every stage.
Johsean offering personalized machine designs with options for reduced carbon footprint. Our pioneering, robust, and patented solutions are designed to optimize production efficiency through customized blowing processes to suit your specific demands.
Explore the evolution of our blow molding technology and discover how it can elevate your future PET machine production!
Features
Fully Automated Operation
Energy-saving technology are frequently used into full automatic machines to reduce power usage during operation.
High Production Capacity
Fully automatic blow molding machines are perfect for high-volume production because they can crank out a lot of bottles per minute.
Flexibility
They provide manufacturers versatility because they may be set up to create bottles in a variety of sizes, shapes, and patterns.
Efficient Heating and Cooling Systems
For accurate temperature control during the blow molding process, these machines are outfitted with cutting-edge heating and cooling systems.
User-Friendly Interface
Many models come with user-friendly interfaces that make it simple to change settings, track production, and identify problems.
Energy-Efficient Design
Energy-saving technology are frequently used into full automatic machines to reduce power usage during operation.
Benefits
High Productivity: Full automatic blow molding machines have a remarkable capacity for production, which boosts overall output and shortens production times.
Consistency: Automation guarantees uniform bottle shapes, constant product quality, and fewer manufacturing flaws.
Labor Savings: These machines require little manual assistance, which lowers labor costs and eliminates the need for skilled operators, making them efficient.
Waste reduction: Exact control over the blow molding procedure lowers material waste and raises manufacturing efficiency as a whole.
Customization for Various Industries: Due to their adaptability, these machines are employed in a variety of industries, including the food and beverage, cosmetics, pharmaceutical, and more.
Energy Efficiency: Many models include energy-efficient elements that cut down on power usage and support sustainability programs.
